Product Model
NetSure 2000 Series
NetSure 2100 Series
The NetSure™ 2000 series is a global family of high-density DC power subracks designed for network access applications. Featuring industry leading high density rectifiers in conjunction with an advanced controller, this system delivers >95% efficiency and withstands demanding environmental conditions. Available with integrated distribution for easy connection to a variety of networking devices.
Models vary by region.
Specifications
Technical Specifications
NetSure 2100 Series
- Environmetal & Standard Compliance
- Operating Temperature
- -40 °C to 70 °C (-40 °F to 158 °F)
- Safety Compliance
- UL 1801 Recognized
- EMC Compliance
- Conforms to FCC rules Part 15, Subpart B, Class B and EN55022 Class B, radiated and conducted
NetSure 2100 Series
The NetSure 2000 Series is designed for wireless access and customer premise applications offering unmatched temperature performance and high power density.
Benefits
Easy to deploy in small spaces with a compact-sized 19" wide shelf, less than 11" deep
Optimize total cost of ownership with >95% high-efficiency eSure™ rectifiers
Save CapEx and OpEx on climate systems in outdoor applications with rectifiers that operate from -40°C to +70°C
Reduce the need for costly site visits with intelligent remote access and monitoring over standard protocols
Features
Highdensity subrack delivers up to 3kW in 1U rack space
Wide operating voltage range, 85-300VAC
All breakers are accessible from the front side
Integrated distribution
Advanced intelligent battery management system
Built-in communication & dry contact ports that enable remote monitoring
